4.0 Configuration
Specify the subnet mask of the local network address.
Enter the Gateway for the local group network.
Remote Group Setup
Specify the method for identifying the router to establish the VPN tunnel.
The Local Security Gateway is on this router; the Remote Security
Gateway is on the other router. At least one of the routers must have either
a static IP address or a dynamic IP with server id to make a connection.
(See Local Group Setup for details)
If the remote VPN router has a static IP address, enter the IP address of
the remote VPN Gateway here.
This option appears when the Remote Security Gateway Type specifies
that the Server ID is required for the connection. The Server ID must be in
the format @name, where name can be anything. Both routers must know
each others names to establish a connection.
Next-hop Gateway means the next-hop gateway IP address for the local or
remote gateway participant's connection to the public network.
Define the remote network by specifying the local subnet.
Specify the subnet mask of the remote network address.
© Microhard Systems Inc.
Group Subnet Mask
Values (IP Address)
255.255.255.0
Group Subnet Gateway
Values (IP Address)
(no default)
Remote Security Gateway Type
Values (selection)
IP Only
IP + Server ID
Dynamic IP + Server ID
Gateway IP Address
Values (IP Address)
(no default)
Values (IP Address)
(no default)
Next-hop Gateway IP
Values (IP Address)
(no default)
Subnet IP Address
Values (IP Address)
(no default)
Subnet Mask
Values (IP Address)
255.255.255.0
Server ID
