Systick Register Map; Table 54. Systick Register Map And Reset Values - ST STM32F4 Series Programming Manual

Core peripherals
4.5.6

SysTick register map

The table provided shows the SysTick register map and reset values. The base address of
the SysTick register block is 0xE000 E010.
Offset Register
STK_CTRL
0x00
Reset Value
STK_LOAD
0x04
Reset Value
STK_VAL
0x08
Reset Value
STK_CALIB
0x0C
Reset Value
250/260

Table 54. SysTick register map and reset values

Reserved
Reserved
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Reserved
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Reserved
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
DocID022708 Rev 6
Reserved
0
RELOAD[23:0]
CURRENT[23:0]
TENMS[23:0]
PM0214
1 0 0
