Systick Register Map; Table 55. Systick Register Map And Reset Values - ST STM32H7 Series Programming Manual

PM0214
4.5.6

SysTick register map

The table provided shows the SysTick register map and reset values. The base address of
the SysTick register block is 0xE000 E010.
Offset Register
STK_CTRL
0x00
Reset Value
STK_LOAD
0x04
Reset Value
STK_VAL
0x08
Reset Value
STK_CALIB
0x0C
Reset Value

Table 55. SysTick register map and reset values

Reserved
Reserved
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Reserved
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Reserved
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
PM0214 Rev 9
Reserved
0
RELOAD[23:0]
CURRENT[23:0]
TENMS[23:0]
