Parameter Descriptions

4.10 Parameters: 9-** PROFIdrive

9-00 Setpoint
Range:
0 [0 -
*
65535 ]
4 4
9-07 Actual Value
Range:
0 [0 - 65535 ] This parameter delivers the MAV for a Master
*
9-15 PCD Write Configuration
Select the parameters to be assigned to PCD 3–10 of the
telegrams. The number of available PCDs depends on the
telegram type. Values in PCD 3–10 are written to the selected
parameters as data. For standard PROFIBUS telegrams, see
parameter 9-22 Telegram Selection.
Option:
[0]
[302]
[303]
[312]
[341]
[342]
[351]
[352]
[380]
[381]
[412]
[414]
[416]
[417]
[553]
[558]
[590]
[593]
[595]
[615]
[625]
[696]
[748]
[890]
[891]
[1680]
[1682]
[3401]
[3402]
78
Function:
This parameter receives cyclic reference from a
Master Class 2. If the control priority is set to
Master Class 2, the reference for the frequency
converter is taken from this parameter, whereas
the cyclical reference is ignored.
Function:
Class 2. The parameter is valid if the control
priority is set to Master Class 2.
Minimum Reference
Maximum Reference
Catch up/slow Down Value
Ramp 1 Ramp Up Time
Ramp 1 Ramp Down Time
Ramp 2 Ramp Up Time
Ramp 2 Ramp Down Time
Jog Ramp Time
Quick Stop Ramp Time
Motor Speed Low Limit [Hz]
Motor Speed High Limit [Hz]
Torque Limit Motor Mode
Torque Limit Generator Mode
Term. 29 High Ref./Feedb. Value
Term. 33 High Ref./Feedb. Value
Digital & Relay Bus Control
Pulse Out 27 Bus Control
Pulse Out 29 Bus Control
Terminal 53 High Ref./Feedb.
Value
Terminal 54 High Ref./Feedb.
Value
Terminal 42 Output Bus Control
PCD Feed Forward
Bus Jog 1 Speed
Bus Jog 2 Speed
Fieldbus CTW 1
Fieldbus REF 1
PCD 1 Write For Application
PCD 2 Write For Application
Danfoss A/S © 7/2015 All rights reserved.
®
VLT AutomationDrive FC 360
9-15 PCD Write Configuration
Select the parameters to be assigned to PCD 3–10 of the
telegrams. The number of available PCDs depends on the
telegram type. Values in PCD 3–10 are written to the selected
parameters as data. For standard PROFIBUS telegrams, see
parameter 9-22 Telegram Selection.
Option:
[3403]
[3404]
[3405]
[3406]
[3407]
[3408]
[3409]
[3410]
9-16 PCD Read Configuration
Select the parameters to be assigned to PCD 3–10 of the
telegrams. The number of available PCDs depends on the
telegram type. Values in PCD 3 to 10 contain the actual data
values of the selected parameters.
Option:
Function:
[0]
[1500]
[1501]
[1502]
[1600]
[1601]
[1602]
[1603]
[1605]
[1609]
[1610]
[1611]
[1612]
[1613]
[1614]
[1615]
[1616]
[1618]
[1622]
[1630]
[1633]
[1634]
[1635]
[1638]
[1639]
[1650]
[1652]
[1653]
[1657]
[1660]
[1661]
[1662]
PCD 3 Write For Application
PCD 4 Write For Application
PCD 5 Write For Application
PCD 6 Write For Application
PCD 7 Write For Application
PCD 8 Write For Application
PCD 9 Write For Application
PCD 10 Write For Application
Operating hours
Running Hours
kWh Counter
Control Word
Reference [Unit]
Reference [%]
Status Word
Main Actual Value [%]
Custom Readout
Power [kW]
Power [hp]
Motor Voltage
Frequency
Motor current
Frequency [%]
Torque [Nm]
Motor Thermal
Torque [%]
DC Link Voltage
Brake Energy /2 min
Heatsink Temp.
Inverter Thermal
SL Controller State
Control Card Temp.
External Reference
Feedback[Unit]
Digi Pot Reference
Feedback [RPM]
Digital Input
Terminal 53 Setting
Analog Input 53
Function:
Function:
MG06C602
