Phaser 6180 Color Laser Printer Service Manual
Signal Line Name
CLOCK
DATA
ADC SOL ON (L) +24 VDC
ADC SENSOR
LED REM
ADC V MONI
DATA
CLOC
TEMP.
HUMI.
ERASE K ON (L) +3.3 VDC
ERASE Y/M/C ON (L) +3.3
VDC
Plug/Jack and Wiring Diagrams
Description
Controls signal of the EEPROM Board.
On/Off signal of the ADC Solenoid.
Toner patch density data measured by the ADC Sensor
(Analog value).
Removes signal of the LED of the ADC Sensor.
Controls signal of the ADC Sensor.
Controls signal of the EEPROM Board.
Temperature data in the printer by the Humidity/
Temperature Sensor (Analog value).
Provides Humidity/Temperature data in the printer by
the Humidity/Temperature Sensor (Analog value).
On/Off signal of the LED.
10-41
