Phaser 6180 Color Laser Printer Service Manual
Service Diagnostic Test Table (continued)
Test Control Panel Display
Edit NVM Edit NVM
Ad0000=00000000*
■
Please wait
■
<Press the Left or Right
button to move the
cursor>
<Press the Up or Down
button to change the
value at the cursor>
<Press the Set button to
save the value in Engine
NVM>
<Press the Cancel button
to move one level up the
menu>
Save NVM Save NVM
SaveNVM MCU -> ESS
■
OK?
Saved
■
Please wait
■
<Press the Set button to
save the value in the
Controller NVM>
<Press the Cancel button
to move one level up the
menu>
Load NVM Load NVM
LoadNVM MCU -> ESS
■
OK?
Processing
■
Loaded
■
Please wait
■
<Press the Set button to
load the value saved in
the Controller NVM to the
Engine>
<Press the Cancel button
to move one level up the
menu>
Initialize Slave Initialize Slave
Initialize Slave OK?
■
Processing
■
Initialized
■
Please wait
■
<Press the Set button to
run Slave Initialization>
<Press the Cancel button
to move one level up the
menu>
General Troubleshooting
Test Description
Displays the current NVRAM value.
Use this function to edit NVRAM
information.
Saves the NVRAM information of the
Engine in the Controller. NVRAM
addresses to be saved are as follows:
1000-10FF, Total: 256Byte
Note: Information saved in the
Controller NVM can be initialized using
Clear All NVM.
Loads NVRAM information of the
Engine saved in the Controller into the
Engine.
1000-10FF / 1100-11FF / 1200-12FF
Note: Information saved in the
Controller NVM can be initialized using
Clear All NVM.
Initializes Slave.
4-17
