Duplex Plug/Jack Designators
Phaser 6180 Color Laser Printer Service Manual
Duplex Plug/Jack Designators
P/J
Map
Coordinates
1
5
E-168
J427
5
F-168
J428
5
F-168
J429
5
F-169
J430
5
F-168
J431
5
F-168
J2720
5
I-169
J4301
5
E-167
Plug/Jack and Wiring Diagrams
Remarks
Not connected (Debug only).
Connects Duplex Board and Duplex Fan.
Connects Duplex Board and Duplex Unit Harness.
Connects Duplex Board and Duplex Motor.
Connects Duplex Board and Duplex Sensor
Harness.
Connects Duplex Board and Duplex Clutch.
Connects Duplex (Duplex Unit Harness) and printer.
Connects Duplex Jam Sensor and Duplex Sensor
Harness.
10-7
