Error Messages and Codes

Check Cartridge (Yellow/Magenta/Cyan/Black)

Applicable Chain Links
Initial Actions
3-40
The Print Cartridge (Yellow/Magenta/Cyan/Black) tape was not removed
when a new Print Cartridge is installed.
■
Chain Link 093-919: Check Yellow Cartridge
■
Chain Link 093-920: Check Magenta Cartridge
■
Chain Link 093-921: Check Cyan Cartridge
■
Chain Link 093-922: Check Black Cartridge
■
Check the Print Cartridge life using CentreWare IS.
■
Cycle printer power.
■
If problem persists, follow the procedure below.
Troubleshooting Reference Table
Applicable Parts
Print Cartridge (Y/M/C/K),
■
PL5.1.18-21
MCU Board, PL9.1.20
■
Dispenser, PL5.1.12
■
Top LV Harness, PL10.1.16
■
Troubleshooting Procedure Table
Step Actions and Questions
1 Check the Print Cartridge tape. Has the
tape been removed?
Does the error still occur?
2
3 Replace the Print Cartridge (page 8-9).
Does the error still occur?
Wiring and Plug/Jack Map References
"Map 3 - Image Processor Board and
■
Dispenser" on page 10-12
"Map 4 - LVPS and MCU Board" on
■
page 10-13
"Developer" on page 10-44
■
Yes
Go to step 2.
Go to step 3.
Go to step 4.
Phaser 6180 Color Laser Printer Service Manual
No
Remove the
tape on the
Print Cartridge.
Go to step 2.
Complete.
Complete.
