Phaser 6180 Color Laser Printer Service Manual
Signal Line Name
FEED CL ON (L) +24 VDC
Outline of Size Switch
The paper size is determined by a combination of On/Off statuses of the SW
1, SW 2, and SW 3 switches of the Size Switch.
Paper Size
Letter (SEF)
A4 (SEF)
A5
B5 (SEF)
Legal 13" (SEF)
Legal 14" (SEF)
Executive (SEF)
No Tray
Note
The Actuator is pushing the Size Switch.
Switch 1
Switch 2
Switch 3
Size Switch
Plug/Jack and Wiring Diagrams
Description
On/Off signal of the Feed Clutch.
Switches
SW 1
SW 2
Off
Off
Off
On
Off
On
On
Off
On
On
On
On
On
Off
Off
Off
s6180-288
SW 3
On
On
Off
Off
Off
On
On
Off
10-37
