General Troubleshooting
4-16
Service Diagnostic Test Table (continued)
Test Control Panel Display
Cyan Toner Cyan Toner Motor
Motor
Black Toner Black Toner Motor
Motor
Regi Clutch Regi Clutch
Tray1 (MPT) Tray1(MPT) Turn Clutch
Turn Clutch
Tray 1 (MPT) Tray1(MPT) Feed
Feed Solenoid Solenoid
Tray 2 Feed Tray 2 Feed Clutch
Clutch
Tray 3 Feed Tray 3 Feed Clutch
Clutch
Tray 3 Turn Tray 3 Turn Clutch
Clutch
Duplex Clutch Duplex Clutch
ADC (TCD) ADC (TCD) Sensor
Sensor Solenoid
Solenoid
ADC (TCD) ADC (TCD) Sensor LED
Sensor LED
OHP Sensor OHP Sensor LED
LED
Drum Erase Drum Erase Lamp K
Lamp K
Drum Erase Drum Erase Lamp YMC
Lamp YMC
Exit Clutch Exit Clutch
Duplex Fan Duplex Fan
NVM Settings <Press the Up or Down
button to move from one
item to another>
<Press the Cancel button
to move one level up the
menu>
<Press the Set button to
move to the execution
level>
Test Description
Tests the cyan Toner Motor.
Tests the black Toner Motor.
Tests the Registration Clutch.
Tests the Tray 1 Turn Clutch.
Tests the Tray 1 Feed Solenoid.
Tests the Tray 2 Feed Clutch.
Tests the Tray 3 Feed Clutch.
Tests the Tray 3 Turn Clutch.
Tests the Duplex Clutch.
Tests the ADC Sensor Solenoid.
Tests the ADC Sensor LED.
Tests the OHP Sensor LED.
Tests the black Erase Lamp.
Tests the yellow, magenta, and cyan
Erase Lamps.
Tests the Exit Clutch.
Tests the Duplex Fan.
Edits, saves, loads, and prints NVRAM
information.
