Load Tray 2 (Paper Mismatch)

Phaser 6180 Color Laser Printer Service Manual
The paper size mismatch is detected in Tray 2.
Applicable Chain Link
■ Chain Link
Initial Actions
■
Inspect the tray to ensure that it is free of obstructions, is loaded with
supported paper, and the guides are adjusted correctly.
■
Cycle printer power.
■ If the problem persists, follow the procedure below.
Troubleshooting Reference Table
Applicable Parts
Tray 2, PL2.1.1
■
Size Switch, PL7.1.18
■
MCU Board, PL9.1.20
■
Registration Sensor Harness,
■
PL3.2.37
Right Side Harness, PL10.1.15
■
Registration Sensor, PL3.2.30
■
Feeder Unit, PL3.2.1
■
Tray 2 Retard Roll, PL2.2.17
■
Troubleshooting Procedure Table
Step Actions and Questions
Check the paper size. Does the paper
1
size meet the specifications?
Check the paper size setting. Does the
2
paper match with the settings in the
Control Panel?
Does the error still occur?
3
4 Reseat the paper End Guide. Does the
error still occur?
Replace Tray 2. Does the error still
5
occur?
024-910: Load Tray 2
Wiring and Plug/Jack Map Reference
"Map 1 - Electrical and Drive" on
■
page 10-10
"Map 2 - Laser Unit" on page 10-11
■
"Map 4 - LVPS and MCU Board" on
■
page 10-13
"Main Drive" on page 10-34
■
"Feeder" on page 10-36
■
Error Messages and Codes
Yes No
Go to step 2. Replace the
paper with the
correct
specifications.
Go to step 4. Correct the
paper settings
in the Control
Panel.
Go to step 4. Complete.
Go to step 5. Complete.
Replace the Complete.
MCU Board
(page 8-87).
