Print-Quality Troubleshooting
Random Spots
Initial Actions
5-42
There are spots of toner randomly scattered across the page.
■
Check the paper transfer path.
■
Ensure there are no debris on the transfer path.
Troubleshooting Reference Table
Applicable Notes
Transfer Unit, PL4.1.1
■
Print Cartridge (C/M/Y/K),
■
PL5.1.18-21
Laser Unit, PL5.1.2
■
Fuser, PL6.1.10
■
MCU Board, PL9.1.20
■
Image Processor Board, PL9.1.27
■
Warning
Ensure to wait for the Fuser to cool down before starting the procedure.
Troubleshooting Procedure Table
Step
Actions and Questions
1
Check for spot's regular intervals. Are
there any spots on the page?
Example Print
ABCDE abcde 12345
Yes
Refer to "The
following table
lists the print-
quality defect
corrective
procedure, their
definition, and
the page where
each procedure
is provided." on
page 5-23.
Phaser 6180 Color Laser Printer Service Manual
s6180-325
No
Go to step 2.
