General Troubleshooting

Service Diagnostics Menu Map

Menu Map - Page 1
To access Service Mode, press Up and Down Arrows at power ON.
ESS Diag
All Test
CodeROM Test
FontROM Test
EEPROM Test
DRAM Test
MAC+PHY Test
ASIC Test
PANEL Test
Engine Test
Engine Diag
Sensor Test
Motor Test
NVM Settings
Print Info
Info Page
Print Settings
Installation
SerialNo.
Tone Correction
Display Counter
HexDump
Pixel Counter
Configuration
Counter Type
Print Counter
CopyCounter MtoB
CopyCounter BtoM
Clear All NVM
Clear JobHistory
Clear AuditronPV
4-6
OK
Exit
Service Mode
DuplexJamSensor
Exit Sensor
Regi Sensor
ROS Ready
Interlock Switch
CRU Sensor Y
CRU Sensor M
CRU Sensor K
CRU Sensor C
Tray 3 Low Paper
Tray 3 No Paper
Duplex Fan Alarm
Tray3 FdMotorAlm
MPT No Paper
Tray 2 No Paper
Main Motor Alarm
Sub Motor Alarm
FAN Alarm
Tray 2 Motor Alarm
DEVE Motor Alarm
Tray2 Paper Size
Tray3 Paper Size
Color Print
B/W Print
Total Print
Color Backup
B/W Backup
Total Backup
Color Error
B/W Error
Power Saver
On/Off
Edit NVM
Save NVM
Load NVM
Initialize Slave
Print NVM Info
Dip Switch0
Dip Switch1
Dip Switch2
Dip Switch3
Type1
Type2
Type3
Type4
Phaser 6180 Color Laser Printer Service Manual
Main Motor (FULL2)
Main Motor (FULL1)
Main Motor (HALF)
Main Motor (LOW)
Sub Motor (FULL2)
Sub Motor (FULL1)
Sub Motor (HALF)
Sub Motor (LOW)
Tray 2 Motor (FULL2)
Tray 2 Motor (FULL1)
Tray 2 Motor (HALF)
Tray 2 Motor (LOW)
Deve Motor (FULL2)
Deve Motor (FULL1)
Deve Motor (HALF)
Duplex Motor (HIGH)
Duplex Motor (FULL2)
Duplex Motor (FULL1)
Duplex Motor (HALF)
Duplex Motor (LOW)
Tray 3 Feed Motor (FULL2)
Tray 3 Feed Motor (FULL1)
Tray 3 Feed Motor (HALF)
Tray 3 Feed Motor (LOW)
Fan (HIGH)
Fan (LOW)
Yellow Toner Motor
Magenta Toner Motor
Cyan Toner Motor
Black Toner Motor
Regi Clutch
Tray1(MPT) Turn Clutch
Tray1(MPT) Feed Solenoid
Tray 2 Feed Clutch
Tray 3 Feed Clutch
Tray 3 Turn Clutch
Duplex Clutch
ADC (CTD) Sensor Solenoid
ADC (CTD) Sensor LED
OHP Sensor LED
Drum Erase Lamp K
Drum Erase Lamp YMC
Exit Clutch
Duplex Fan
