7 WATCHDOG TIMER (WDT)
7.2.2

Clock Supply in DEBUG Mode

The CLK_WDT supply during DEBUG mode should be controlled using the WDTCLK.DBRUN bit.
The CLK_WDT supply to WDT is suspended when the CPU enters DEBUG mode if the WDTCLK.DBRUN bit = 0.
After the CPU returns to normal mode, the CLK_WDT supply resumes. Although WDT stops operating when the
CLK_WDT supply is suspended, the register retains the status before DEBUG mode was entered.
If the WDTCLK.DBRUN bit = 1, the CLK_WDT supply is not suspended and WDT will keep operating in DE-
BUG mode.
7.3

Operations

7.3.1

WDT Control

Starting up WDT
WDT should be initialized and started up with the procedure listed below.
1. Write 0x0096 to the MSCPROT.PROT[15:0] bits.
2. Configure the WDT operating clock.
3. Configure the WDTCTL.NMIXRST bit.
4. Write 1 to the WDTCTL.WDTCNTRST bit.
5. Write a value other than 0xa to the WDTCTL.WDTRUN[3:0] bits.
6. Write a value other than 0x0096 to the MSCPROT.PROT[15:0] bits. (Set system protection)
Resetting WDT
WDT generates a system reset (WDTCTL.NMIXRST bit = 0) or NMI (WDTCTL.NMIXRST bit = 1) when the
counter overflows. To avert system restart by WDT, its embedded counter must be reset periodically via soft-
ware while WDT is running.
1. Write 0x0096 to the MSCPROT.PROT[15:0] bits.
2. Write 1 to the WDTCTL.WDTCNTRST bit.
3. Write a value other than 0x0096 to the MSCPROT.PROT[15:0] bits. (Set system protection)
A location should be provided for periodically processing this routine. Process this routine within the t
cycle. After resetting, WDT starts counting with a new NMI/reset generation cycle.
If WDT is not reset within the t
or reset, the interrupt vector is read out, and the interrupt handler routine is executed.
If the counter overflows and generates an NMI without WDT being reset, the WDTCTL.STATNMI bit is set to 1.
7.3.2

Operations in HALT and SLEEP Modes

During HALT mode
WDT operates in HALT mode. HALT mode is therefore cleared by an NMI or reset if it continues for more than the
NMI/reset generation cycle and the NMI or reset handler is executed. To disable WDT in HALT mode, stop WDT by
writing 0xa to the WDTCTL.WDTRUN[3:0] bits before executing the halt instruction. Reset WDT before resuming
operations after HALT mode is cleared.
During SLEEP mode
WDT operates in SLEEP mode if the selected clock source is running. In this case SLEEP mode is cleared by an NMI
or reset if it continues for more than the NMI/reset generation cycle and the NMI or reset handler is executed. There-
fore, stop WDT by setting the WDTCTL.WDTRUN[3:0] bits before executing the slp instruction.
If the clock source stops in SLEEP mode, WDT stops. To prevent generation of an unnecessary NMI or reset after
clearing SLEEP mode, reset WDT before executing the slp instruction. WDT should also be stopped as required using
the WDTCTL.WDTRUN[3:0] bits.
7-2
cycle for any reason, the CPU is switched to interrupt processing by NMI
WDT
Seiko epson Corporation
(Remove system protection)
(Select NMI or reset mode)
(Reset WDT counter)
(Start up WDT)
(Remove system protection)
(Reset WDT counter)
S1C17F13 TeChniCal Manual
WDT
(Rev. 1.0)
