TROUBLESHOOTING
STEP
1 Was "ENGINE DIAG. FLOW TABLE" performed?
2 Does speedometer indicate vehicle speed?
3 VSS Power Supply Voltage Check:
1) With ignition switch OFF, remove VSS coupler.
2) With ignition switch ON leaving engine OFF, check
voltage between "BLK/WHT" wire terminal and
"BLK" wire terminal of VSS coupler.
Is voltage 10 – 14 V?
4 VSS Signal Harness Check:
1) With ignition switch ON leaving engine OFF, check
voltage between "BLU/YEL" wire terminal and
"BLK" wire terminal of VSS coupler.
Is voltage 4 V or more?
5 VSS Visual Inspection:
1) Remove VSS referring to "TRANSFER" section.
2) Check VSS drive and driven gears for damage and
excessive wear.
Are they in good condition?
6 Speedometer Circuit Check:
1) With ignition switch OFF, disconnect G11 coupler
from combination meter.
2) With ignition switch ON leaving engine OFF, check
voltage between "BLU/YEL" wire terminal and
"BLK" wire terminal of VSS coupler.
Is voltage 4 V or more?
ENGINE DIAGNOSIS (RHZ ENGINE WITH SINGLE-CONNECTOR ECM) 6-73
ACTION YES
Go to Step 2.
Faulty "BLU/YEL"
wire or poor C51-19
connection.
If wire and connec-
tion are OK, intermit-
tent trouble or faulty
ECM.
Check for intermittent
referring to "Intermit-
tent and Poor Con-
nection" in Section
0A.
Go to Step 4.
Go to Step 5.
Poor VSS connection
or VSS malfunction.
If connection is OK,
substitute a known-
good VSS and
recheck.
Substitute a known-
good combination
meter and recheck.
NO
Go to "ENGINE
DIAG. FLOW
TABLE".
Go to Step 3.
"BLK/WHT" or "BLK"
wire open/short.
Go to Step 6.
Replace VSS.
"BLU/YEL" wire
open/short or faulty
ECM.
If wire and connec-
tion are OK, substi-
tute a known-good
ECM and recheck.
