4. Return the server to operation.
a. Install the server top cover.
b. Return the server to the normal rack position.
c. Connect any data cables you removed to service the PCIe cards.
d. Reconnect the power cord (or cords) to the power supply (or supplies).
5. Use ILOM to clear the server PCIe riser fault.
For instructions for clearing an PCIe riser faults, see the Oracle Integrated Lights
Out Manager (ILOM) 3.0 Supplement for Sun Fire X4170 M2 and X4270 M2 Servers
(821-0489).
4.5

Servicing PCIe Cards

See Section 4.5.2, "PCIe Card Configuration Guidelines" on page 4-22
configuration guidelines.
Caution – These procedures require that you handle components that are sensitive
to static discharge. This sensitivity can cause the component to fail. To avoid damage,
ensure that you follow antistatic practices as described in
Electrostatic Discharge and Antistatic Prevention Measures" on page
Caution – Ensure that all power is removed from the server before removing or
installing expansion cards. You must disconnect the power cables before performing
these procedures.
The following topics are covered in this section:
Section 4.5.1, "Supported PCIe Cards" on page 4-21
■
Section 4.5.2, "PCIe Card Configuration Guidelines" on page 4-22
■
Section 4.5.3, "Remove a PCIe Card" on page 4-23
■
Section 4.5.4, "Install a PCIe Card" on page 4-24
■
4-20 Sun Fire X4270 M2 Server Service Manual • May 2011
See Section 6.2, "Installing the Server Top Cover" on page
See Section 6.4, "Returning the Server to the Normal Rack Position" on
page 6-5.
See Section 6.5, "Powering On the Server" on page
Verify that the AC Present LED is lit.
6-2.
6-7.
for PCIe card
Section 2.9, "Performing
2-31.
