TABLE 3-3
HBA Controller Type
For Sun Storage
For LSI MegaRAID
Storage Manager (MSM)
■
3.2.5

Remove Boot Drive

1. Identify the Boot drive you want to remove.
The amber Service Action Required LED might be lit. For specific drive locations,
see
2. Remove the boot drive (
a. On the drive that you want to remove, push the boot drive release button to
b. Grasp the boot drive latch and pull the drive out of the drive slot [2].
Caution – The boot drive latch is not an ejector. Do not bend it too far to the right.
Doing so can damage the latch.
Caution – Whenever you remove a boot drive, you should replace it with another
boot drive or a filler panel before you power on the server; otherwise the server
might overheat due to improper airflow.
For configuration information, refer to
Storage Drive Installation Configuration Information
Refer to...
• LSI MegaRAID SAS Software User's Guide located at:
Note - Open the book PDF file and search on "drive offline."
• Sun LSI 106x RAID User's Guide (820-4933).
Note - Open the book PDF file and search on "drive offline."
If you have cold-plugged the drive:
Restore power to the server. Complete the procedure described in
"Powering On the Server" on page
.
FIGURE 3-3
open the latch [1].
TABLE 3-3
http://www.lsi.com/support/sun/
6-7.
).
FIGURE 3-7
Chapter 3 Servicing Customer-Replaceable Devices
.
Section 6.5,
3-9
