TABLE 1-1
Feature
Internal storage
drives
Boot Drives
Removable media
USB ports
Service ports
Cooling
PCI interfaces
Power
1-2 Sun Fire X4270 M2 Server Service Manual • May 2011
Sun Fire X4270 M2 Server
Description
Available in two configurations:
• Up to 12, 3.5-inch SAS, SATA, or SSD storage drives with HW
RAID controller
or
• Up to 24, 2.5-inch SAS, SATA, or SSD storage drives with HW
RAID controller
Two rear-mounted boot drives (optional).
None
Five USB 2.0 ports, two front, two in rear, one internal.
• One RJ-45 serial management port (SER MGT)
(default connection to access service processor)
• One 10/1000-Mbps network management port (NET MGT)
(to access service processor)
• One HD-15 VGA video port
• Six hot-swappable system fan modules
• An air baffle that facilitates processor/memory airflow
The number of PCIe2 slots supported varies with the server
configuration:
• Server without rear-mounted boot drives: Three risers, each
having two standard low-profile PCIe2 slots, for a total of six x8
slots. Two slots support native x8 electrical/mechanical, and four
slots are active and support switched x8 electrical/mechanical.
or
• Server with rear-mounted boot drives: Two risers, each having
two standard low profile PCIe2 slots, for a total of four x8 slots.
Two slots support native x8 electrical/mechanical, and two slots
are active and support switched x8 electrical/mechanical.
• AC power: 100–120/200–240 V AC, 13/6.5 A, 50–60 Hz
• Up to two hot-swappable 1200W power supply units (PSUs) to
provide N+N redundancy, with energy efficient design
System Features (Continued)
