6.3

Reinstalling the Server in the Rack

If you removed the server chassis from the rack, perform these steps.
Caution – The servers are heavy. Two people might be required to
carry the chassis and install it in the rack.
6.3.1

Reinstall Server in Rack

1. Push the slide-rails into the slide-rail assemblies in the rack as far as possible.
2. Raise the server so that the rear ends of the mounting brackets are aligned with
the slide-rail assemblies that are mounted in the rack (
3. Insert the mounting brackets into the slide-rails, then push the server into the
rack until the mounting brackets encounter the slide-rail stops (approximately
12 inches, or 30 cm).
The server is now in the extended maintenance position.
6-4 Sun Fire X4270 M2 Server Service Manual • May 2011
).
FIGURE 6-3
