1.2.3

Internal System Cables

The server internal cables are listed in
TABLE 1-4
Cable
Top cover interlock cable
Power distribution board
ribbon cable
Power supply ribbon cable
Storage drive data cables
Fan power board cables
Disk backplane cables
Front panel light pipe
assembly cables
Rear-mounted Boot Disk
Drive power and data
cables
1.3

Server Front Panel Features

FIGURE 1-1
3.5-inch, storage drives.
1-6 Sun Fire X4270 M2 Server Service Manual • May 2011
Server Cables
Connects...
To the power distribution board
Between the power distribution board and the motherboard
Between the power distribution board and the power supplies
Between the motherboard HBA PCI-Express card and the SAS
expander board
Between the connector board and fan power board
Between the connector board and disk drive backplane
Between the light pipe assembly and the disk drive backplane
• Power cable: between the boot disk drive assembly to the
motherboard
• Data cables: between the boot disk drive and the on-board
SATA controller
shows front panel features on the Sun Fire X4270 M2 Server with 12,
.
