5.1
Infrastructure Component Locations
The infrastructure components that are replaceable are shown in
Location of Infrastructure Components
FIGURE 5-1
Figure Legend
1
Fan Board
2
SAS Expander Board
3
Disk Backplane
4
Front control Panel Light Pipe Assembly
5-2
Sun Fire X4270 M2 Server Service Manual • May 2011
5
Power Distribution Board
6
Connector Board
7
Power Supply Backplane
.
FIGURE 5-1
