Supported Pcie Cards - Sun Oracle Sun Fire X4270 M2 Service Manual

4.5.1

Supported PCIe Cards

See
installation guide.
Supported PCIe HBA Cards and Applicable Installation Guides
TABLE 4-5
PCIe Card Name and Module Number
Sun Storage 6 Gb SAS RAID PCIe
HBA, Internal
*
(SGX-SAS6-R-INT-Z)
Sun Storage 6 Gb SAS RAID PCIe
HBA, External
(SGX-SAS6-R-EXT-Z)
Sun Storage 6 Gb SAS PCIe HBA,
Internal (SGX-SAS6-INT-Z)
Sun Storage 6 Gb SAS PCIe HBA,
External (SGX-SAS6-EXT-Z)
* If this HBA card is installed in the server, the ambient temperature requirement for the server is reduced from 35
o
(89.6 F).
Note – Some of the SAS PCIe option cards listed in
for purchase at the time of this publication. To determine which SAS PCIe option
cards are supported and available for purchase on the Sun Fire X4270 M2 Server, go
to the following web site and navigate to the appropriate page:
http://www.oracle.com/goto/x4270m2.
for a list of PCIe option cards supported and the applicable
TABLE 4-5
Description
This card connects to internal
storage devices, that is, devices that
are physically located inside the
system chassis and supports RAID.
Connects to external storage devices
and supports RAID.
Connects to internal storage
devices, that is, devices that are
physically located inside the system
chassis.
Note - This PCIe card does not
support RAID.
Connects to external storage
devices.
Note - This PCIe card does not
support RAID.
Refer to...
The "Hardware Installation and
Removal" chapter in the Sun Storage 6
Gb SAS PCIe RAID HBA, Internal
Installation Guide For HBA Models
SGX-SAS6-R-INT-Z and
SG-SAS6-R-INT-Z (820-7885)
The "Hardware Installation and
Removal" chapter in the Sun Storage 6
Gb SAS PCIe RAID HBA, External
Installation Guide For HBA Models
SGX-SAS6-R-EXT-Z and
SG-SAS6-R-EXT-Z (820-7886)
The "Hardware Installation and
Removal" chapter in the Sun Storage 6
Gb SAS PCIe HBA, Internal Installation
Guide For HBA Models
SGX-SAS6-INT-Z and SG-SAS6-INT-Z
(820-7889)
The "Hardware Installation and
Removal" chapter in the Sun Storage 6
Gb SAS PCIe HBA, External
Installation Guide For HBA Models
SGX-SAS6-EXT-Z and
SG-SAS6-EXT-Z (820-7890)
TABLE 4-5
Chapter 4 Servicing Motherboard Components
o o o
C (95 F) to 32 C
might not be available
4-21
