Server Filler Panel Removal and Installation Procedures (Continued)
TABLE 2-7
Filler Panel Type Removal Procedure
Storage Drive 1. Locate the disk drive filler panel to be
removed from the server.
2. To unlatch the disk drive filler panel,
press the release lever button then tilt
the lever up into a fully opened position.
3. To remove the filler panel from the slot,
hold the opened release lever and gently
slide the filler panel toward you.
PCI Slot 1. Remove the server top cover.
2. Remove the PCI slot filler panel from the
location into which you intend to install
the PCIe card.
Power supply 1. To release the filler panel side latches,
use your fingers to press and hold both
sides of the filler panel away from the
sides of the power supply bay.
2. Using fingers on your other hand, grasp
the lip at the bottom of the filler panel
and pull it out of the power supply bay.
2.9 Performing Electrostatic Discharge and
Antistatic Prevention Measures
2.9.1

Electrostatic Discharge Safety Measures

Electrostatic discharge (ESD) sensitive devices, such as the motherboards, PCIe cards,
storage drives, and memory cards, require special handling.
Install Procedure
1. Locate the vacant disk drive module slot in
the server, then ensure that the release lever
on the filler panel is fully opened.
2. Slide the filler panel into the vacant slot by
pressing the middle of the filler panel
faceplate with your thumb or finger.
The release lever will lower as it makes
contact with the chassis. Do not slide the
filler panel in all the way. Leave the filler
panel out approximately 0.25 to 0.50 inch (6
to 12 mm) from the opening
3. Using your thumb or finger, press on the
middle of the filler panel faceplate until the
release lever engages with the chassis.
4. Close the release lever until it clicks into
place and is flush with the front of the server.
1. Remove the server top cover.
2. Press the PCI filler panel into the vacant PCI
slot.
1. Position the filler panel in the power supply
bay so that the closed end is facing inward
and the lip that is used to remove the filler
panel is in the bottom position.
2. Press the filler panel into the power supply
bay until it is flush with the power supply
bay.
Chapter 2 Preparing to Service the System 2-31
