Connector Pinouts - Sun Oracle Sun Fire X4270 M2 Service Manual

A
A P P E N D I X

Connector Pinouts

This appendix provides reference information about the Sun Fire X4270 M2 Server
back panel ports and pin assignments.
Topics covered in this appendix include:
Section A.1, "Serial Management Port Connector" on page A-2
■
Section A.2, "Network Management Port Connector" on page A-3
■
Section A.3, "Video Connector" on page A-4
■
Section A.4, "USB Connectors" on page A-5
■
Section A.5, "Gigabit Ethernet Connectors" on page A-6
■
For the locations of the back panel ports on the servers, see and
FIGURE 1-3 FIGURE 1-4
.
A-1
