Memory DIMM Fault LED Locations
FIGURE 4-4
c. To remove the faulty DIMM do the following:
d. Replace each faulty DIMM with either another DIMM of the same rank size
Caution – If you are not immediately inserting a replacement DIMM into the empty
DIMM socket, insert a DIMM filler panel in the socket to ensure adequate cooling
and reduce the possibility of a system shutdown. For instructions for installing a
DDR3 filler panel, see
page
4-10 Sun Fire X4270 M2 Server Service Manual • May 2011
i. Rotate both DIMM slot ejectors outward as far as they will go.
The DIMM is partially ejected from the socket (
ii. Carefully lift the DIMM straight up to remove it from the socket.
(quad rank, dual rank, or single rank) or a DIMM filler panel.
For DIMM replacement instructions, see
on page 4-11.
Section 2.8.2, "Filler Panel Removal and Installation" on
2-30.
).
FIGURE 4-5
Section 4.2.7, "Install DDR3 DIMMs"
