1
C H A P T E R
Sun Fire X4270 M2 Server Overview
This chapter provides an overview of the features of the server.
The following information is included:
"Product Description" on page 1-1
■
Section 1.2, "Server Chassis Overview" on page 1-3
■
Section 1.3, "Server Front Panel Features" on page 1-6
■
Section 1.4, "Server Back Panel Features" on page 1-9
■
Section 1.5, "Server Status Indicators and LEDs" on page 1-10
■
1.1 Product Description
The server is an enterprise-class two-socket rackmount x64 system powered by the
Intel Xeon processor, packing high-performance and expansion capability into a
compact 2 rack unit footprint.
The Sun Fire X4270 M2 Server product features are listed in
TABLE 1-1
Feature
Processor
Memory
Ethernet ports
Sun Fire X4270 M2 Server
Description
• Intel Xeon processor 5600 series
• Supports up to two processors with two Intel processor sockets
18 slots for DDR3 DIMMs: Up to 144 GB of 1333-MHz ECC
registered DDR3 memory
Four ports, 10/100/1000 Mbps, auto-negotiating through two
separate controllers
System Features
.
TABLE 1-1
1-1
