Kyocera Mita DC-2560 Service Manual page 417

1AH
Problem
(6) Check if the paper is excessively
Paper misfeed. curled.
The guide plate along the paper
conveying path is deformed.
Check if the upper and lower
registration rollers are in contact with
each other correctly.
Check if the paper conveying belt is
off the paper conveying pulleys.
Check if the upper or lower fixing
guide is deformed.
Check if the press roller is extremely
dirty or deformed.
Check if the heat roller and claws are
in contact with each other correctly.
Check if the eject roller and pulley are
in contact correctly.
(7) Check if the developing unit is
Toner drops on extremely dirty.
the paper
conveying path.
(8) Check if the pulleys, rollers or gears
Abnormal noise move smoothly.
is heard.
Check if the following electromagnetic
clutches are installed correctly: upper
and lower feed clutches, upper and
lower paper feed clutches, and
bypass paper feed clutch.
3-6-46
Causes/check procedures Corrective measure
Change the paper if
necessary.
Check visually and correct
or replace if necessary.
Repair if necessary.
Replace the crimp-style
spring if it is deformed.
Repair.
Repair or replace.
Clean or replace (see page
3-3-95).
Repair if the heat roller claw
spring of the heat roller is
off.
Repair if the crimp-style
spring of the eject pulley is
off.
Clean the developing unit.
Grease the bearings and
gears.
Correct.
