4. Remove the three screws, and then the cleaning blade.
* Attach the cleaning blade not so as to run on to the projection of the blade
attachment plate.
Cleaning blade
Blade atta-
chment plate
5. Refit all the removed parts.
6. Push up the blade attachment plate, slide the blade lever toward the front to put the
cleaning blade to the drum. (see page 3-3-84)
7. Refit the image formation unit to the machine, and then close the front cover.
Screws
Projection
Figure 3-3-77
1AH
3-3-85
