Kyocera Mita DC-2560 Service Manual page 395

1AH
Terminals (CN)
1-1 1-2
1-3 1-2
1-4 14-3
1-5 14-3
1-6 14-3
1-7 14-4
1-8 14-4
1-9 14-4
1-10 14-4
1-11 14-4
1-12 14-4
1-13 14-4
1-14 14-3
2-10 14-4
2-11 14-4
2-12 14-4
2-13 14-4
2-14 2-15
2-16 2-15
2-17 2-19
2-18 2-19
2-20 2-22
2-21 2-22
2-23 14-4
2-24 14-4
2-25 14-4
*Optional
3-6-24
Voltage
5/0 V DC
5 V DC
5/0 V DC
5/0 V DC
5/0 V DC
24/0 V DC
24/0 V DC
24/0 V DC
24/0 V DC
5/0 V DC
24 V DC
24/0 V DC
24 V DC
24/0 V DC
5/0 V DC
5 V DC
5 V DC
5/0 V DC
5/0 V DC
5 V DC
24/0 V DC
24 V DC
24/0 V DC
Remarks
ODSW off/on, input
5 V DC supply to ODSW, output
DM off/on, output
DM motor lock detection off/on, input
DM forward/reverse, output
HVTPCB developing bias off/on, output
HVTPCB main charging off/on, output
HVTPCB transfer charging output off/on,
output
HVTPCB separation charging output off/
on, output
HVTPCB grid control voltage, output
HVTPCB separation charging control
voltage off/on, output
HVTPCB transfer charging control
voltage off/on, output
HVTPCB main charging output problem
detection off/on, input
24 V DC supply to BYPSOL, output
BYPSOL off/on, output
24 V DC supply to BYPCL, output
BYPCL off/on, output
BYPPSW off/on, input
5 V DC supply to BYPPSW, output
5 V DC supply to RSW, output
RSW off/on, input
FSW off/on, input
5 V DC supply to FSW, output
FCL-U off/on, output
24 V DC supply to FCL-U, output
RCL off/on, output
