Kyocera Mita DC-2560 Service Manual page 397

1AH
Terminals (CN)
5-16 5-14
5-17 5-14
5-19 5-23
5-20 5-23
5-21 5-23
5-22 5-23
5-24 5-26
5-25 5-26
5-27 14-4
5-28 14-4
5-29 114-4
5-30 14-4
6-1 14-4
6-2 14-4
6-3 14-4
6-4 14-4
6-5 14-4
6-7 14-4
6-8 14-4
6-9 14-4
6-10 14-4
6-11 14-4
6-13 6-15
6-14 6-15
6-16 6-18
6-17 6-18
6-19 6-21
6-20 6-21
6-23 6-22
6-24 6-22
7-1 7-4
7-2 7-4
7-3 7-4
7-5 7-4
7-6 7-9
7-7 7-9
7-8 7-9
*Optional
3-6-26
Voltage
24 V DC
5/0 V DC (pulse)
5/0 V DC (pulse)
5/0 V DC (pulse)
5/0 V DC (pulse)
5 V DC
24 V DC
24/0 V DC
24 V DC
24/0 V DC
24/0 V DC (pulse)
24/0 V DC (pulse)
24/0 V DC (pulse)
24/0 V DC (pulse)
24 V DC
24/0 V DC (pulse)
24/0 V DC (pulse)
24/0 V DC (pulse)
24/0 V DC (pulse)
24 V DC
5 V DC
5/0 V DC
5 V DC
5/0 V DC
5 V DC
5/0 V DC
24 V DC
5/0 V DC
5 V DC
5/0 V DC (pulse)
5/0 V DC (pulse)
5/0 V DC
5 V DC
5/0 V DC (pulse)
Remarks
24 V DC supply to TNS, output
TNS control voltage, output
Serial data from OPPCB, input
Serial data to OPPCB, output
Serial data communication clock to
OPPCB, output
Serial data communication data frame
sync to OPPCB, output
OPPCB (LCDTH) detection voltage, input
5 V DC supply to OPPCB, output
24 V DC supply to OPFM2, output
OPFM2 off/on, output
24 V DC supply to OPFM1, output
OPFM1 off/on, output
MM drive, output ( φ 3)
MM drive, output ( φ 2)
MM drive, output ( φ 1)
MM drive, output ( φ 0)
24 V DC supply to MM, output
LM drive, output ( φ 3)
LM drive, output ( φ 2)
LM drive, output ( φ 1)
LM drive, output ( φ 0)
24 V DC supply to LM, output
5 V DC supply to MHPSW, output
MHPSW off/on, input
5 V DC supply to LHPSW, output
LHPSW off/on, input
5 V DC supply to SHPSW, output
SHPSW off/on, input
AES detection voltage, input
24 V DC supply to AES output
ODS 7, 8 LED off/on, output *
5 V DC supply to ODS 7, 8, output *
ODS 7, 8 detection voltage, output *
ODS 7, 8 control voltage, input *
ODS 5, 6 LED off/on, output
5 V DC supply to ODS 5, 6, output
ODS 5, 6 detection voltage, input
*1: For metric models only
