( 6 ) Detaching and refitting the fixing unit blade

Clean or replace the fixing unit blade as follows.
Procedure
1. Remove the fixing unit from the machine. (see page 3-3-90)
2. Remove the upper fixing cover. (see page 3-3-90)
3. Remove the faston terminal of the fixing unit thermostat on the rear of the fixing unit.
4. Remove the two screws and the fixing unit blade.
Fixing unit blade
5. Refit all the removed parts.
Screws
Faston terminal
Figure 3-3-94
1AH
3-3-99
