Ten-Ms Timer: Timh(015)/Timhx - Omron SYSMAC CJ - REFERENCE MANUAL 08-2008 Reference Manual

Timer and Counter Instructions
3-6-2

TEN-MS TIMER: TIMH(015)/TIMHX(551)

Purpose
Ladder Symbol
Variations
Applicable Program Areas
Operands
or
TIMH(015)/TIMHX(551) operates a decrementing timer with units of 10-ms.
The setting range for the set value (SV) is 0 to 99.99 s for TIMH(015) and 0 to
655.35 s for TIMHX(551). The timer accuracy is 0 to 0.01 s.
Note The timer accuracy for CS1D CPU Units is 10 ms + the cycle time
PV
refresh
method
BCD
Binary
Variations Executed Each Cycle for ON Condition
Executed Once for Upward Differentiation
Executed Once for Downward Differentiation Not supported.
Immediate Refreshing Specification
Block program areas
Not allowed
N: Timer Number
The timer number must be between 0000 and 4095 (decimal).
S: Set Value
The set value must be between #0000 and 9999 in BCD mode.
Timer input
CIO 000000
&0100
Timer PV
T0000
Timer
Completion
Flag
T0000
Symbol
TIMH(015)
N: Timer number
N
S S: Set value
TIMHX(551)
N N: Timer number
S S: Set value
Step program areas
OK
Section 3-6
Operands
N: 0000 to 4095 (decimal)
S: #0000 to #9999 (BCD)
N: 00000 to 4095 (decimal)
S: &0 to &65535 (decimal)
#0000 to #FFFF (hex)
TIMH(015)/
TIMHX(551)
Not supported.
Not supported.
Subroutines Interrupt tasks
OK Not allowed
