Data Shift Instructions
3-9-1

SHIFT REGISTER: SFT(010)

Purpose
Ladder Symbol
Variations
Applicable Program Areas
Operand Specifications
Operates a shift register.
Data input
Shift input
Reset input
Variations Executed Each Cycle for ON Condition
Executed Once for Upward Differentiation
Executed Once for Downward Differentiation Not supported
Immediate Refreshing Specification
Block program areas
Not allowed
Note St and E must be in the same data area.
Area
CIO Area
Work Area
Holding Bit Area
Auxiliary Bit Area
Timer Area
Counter Area
DM Area
EM Area without bank
EM Area with bank
Indirect DM/EM
addresses in binary
Indirect DM/EM
addresses in BCD
Constants
Data Registers
Index Registers
Indirect addressing
using Index Registers
SFT(010)
St: Starting word
St
E: End word
E
Step program areas
OK
St
CIO 0000 to CIO 6143
W000 to W511
H000 to H511
A448 to A959
---
---
---
---
---
---
---
---
---
---
,IR0 to ,IR15
–2048 to +2047 ,IR0 to –2048 to +2047 ,IR15
DR0 to DR15, IR0 to IR15
Section 3-9
SFT(010)
Not supported
Not supported
Subroutines Interrupt tasks
OK OK
E
