Omron SYSMAC CJ - REFERENCE MANUAL 08-2008 Reference Manual page 586

Conversion Instructions
Applicable Program Areas
Operand Specifications
Description
546
Function block Block program
definitions areas
OK OK
Area
CIO Area
Work Area
Holding Bit Area
Auxiliary Bit Area
Timer Area
Counter Area
DM Area
EM Area without bank
EM Area with bank
Indirect DM/EM
addresses in binary
Indirect DM/EM
addresses in BCD
Constants
Data Registers
Index Registers
Indirect addressing
using Index Registers
NUM16(606) converts the 16 characters of ASCII data in S to S+7 to numeri-
cal data (4-digit hexadecimal) and writes the result to D and D+3.
The Error Flag will be turned ON if the ASCII data contains any characters
that are not hexadecimal digits. In this case, the instruction will not be exe-
cuted.
Step program
areas
OK
S
CIO 0000 to CIO 6136
W000 to W504
H000 to H504
A448 to A952
T0000 to T4088
C0000 to C4088
D00000 to D32760
E00000 to E32760
En_00000 to En_32760
(n = 0 to C)
@ D00000 to @ D32767
@ E00000 to @ E32767
@ En_00000 to @ En_32767
(n = 0 to C)
*D00000 to *D32767
*E00000 to *E32767
*En_00000 to *En_32767
(n = 0 to C)
---
---
---
,IR0 to ,IR15
–2048 to +2047 ,IR0 to –2048 to +2047 ,IR15
DR0 to DR15, IR0 to IR15
,IR0+(++) to ,IR15+(++)
,–(– –)IR0 to, –(– –)IR15
Section 3-12
Subroutines Interrupt
tasks
OK OK
D
CIO 0000 to CIO 6140
W000 to W508
H000 to H508
A448 to A956
T0000 to T4092
C0000 to C4092
D00000 to D32764
E00000 to E32764
En_00000 to En_32764
(n = 0 to C)
---
---
