Omron SYSMAC CJ - REFERENCE MANUAL 08-2008 Reference Manual page 335

Comparison Instructions
Code Mnemonic
310 LD< LOAD LESS THAN
AND< AND LESS THAN
OR< OR LESS THAN
311 LD<L LOAD DOUBLE LESS THAN
AND<L AND DOUBLE LESS THAN
OR<L OR DOUBLE LESS THAN
312 LD<S LOAD SIGNED LESS THAN
AND<S AND SIGNED LESS THAN
OR<S OR SIGNED LESS THAN
313 LD<SL LOAD DOUBLE SIGNED LESS THAN
AND<SL AND DOUBLE SIGNED LESS THAN
OR<SL OR DOUBLE SIGNED LESS THAN
315 LD<= LOAD LESS THAN OR EQUAL
AND<= AND LESS THAN OR EQUAL
OR<= OR LESS THAN OR EQUAL
316 LD<=L LOAD DOUBLE LESS THAN OR EQUAL
AND<=L AND DOUBLE LESS THAN OR EQUAL
OR<=L OR DOUBLE LESS THAN OR EQUAL
317 LD<=S LOAD SIGNED LESS THAN OR EQUAL
AND<=S AND SIGNED LESS THAN OR EQUAL
OR<=S OR SIGNED LESS THAN OR EQUAL
318 LD<=SL LOAD DOUBLE SIGNED LESS THAN OR EQUAL True if
AND<=SL AND DOUBLE SIGNED LESS THAN OR EQUAL
OR<=SL OR DOUBLE SIGNED LESS THAN OR EQUAL
320 LD> LOAD GREATER THAN
AND> AND GREATER THAN
OR> OR GREATER THAN
321 LD>L LOAD DOUBLE GREATER THAN
AND>L AND DOUBLE GREATER THAN
OR>L OR DOUBLE GREATER THAN
322 LD>S LOAD SIGNED GREATER THAN
AND>S AND SIGNED GREATER THAN
OR>S OR SIGNED GREATER THAN
323 LD>SL LOAD DOUBLE SIGNED GREATER THAN
AND>SL AND DOUBLE SIGNED GREATER THAN
OR>SL OR DOUBLE SIGNED GREATER THAN
325 LD>= LOAD GREATER THAN OR EQUAL
AND>= AND GREATER THAN OR EQUAL
OR>= OR GREATER THAN OR EQUAL
326 LD>=L LOAD DOUBLE GREATER THAN OR EQUAL
AND>=L AND DOUBLE GREATER THAN OR EQUAL
OR>=L OR DOUBLE GREATER THAN OR EQUAL
327 LD>=S LOAD SIGNED GREATER THAN OR EQUAL
AND>=S AND SIGNED GREATER THAN OR EQUAL
OR>=S OR SIGNED GREATER THAN OR EQUAL
328 LD>=SL LOAD DBL SIGNED GREATER THAN OR EQUAL
AND>=SL AND DBL SIGNED GREATER THAN OR EQUAL
OR>=SL OR DBL SIGNED GREATER THAN OR EQUAL
Section 3-7
Name Function
True if
C1 < C2
True if
C1 C2
C1 C2
True if
C1 > C2
True if
C1 C2
295
