Omron SYSMAC CJ - REFERENCE MANUAL 08-2008 Reference Manual page 549

Conversion Instructions
Operand Specifications
Description
Flags
Area
CIO Area
Work Area
Holding Bit Area
Auxiliary Bit Area
Timer Area
Counter Area
DM Area
EM Area without bank
EM Area with bank
Indirect DM/EM
addresses in binary
Indirect DM/EM
addresses in BCD
Constants
Data Registers
Index Registers
Indirect addressing
using Index Registers
HEX(162) treats the contents of the source word(s) as ASCII data represent-
ing hexadecimal digits (0 to 9 and A to F), converts the specified number of
bytes to hexadecimal, and writes the hexadecimal data to the destination
word beginning at the specified digit.
An error will occur if the source words contain data which is not an ASCII
equivalent of hexadecimal digits. The following table shows hexadecimal dig-
its and their ASCII equivalents (excluding parity bits).
Hexadecimal digits (4 bits)
0 to 9
A to F
Note Refer to Appendix A in the CS/CJ-series Programming Consoles Operation
Manual (W341) for a table of extended ASCII characters.
S
CIO 0000 to CIO 6143
W000 to W511
H000 to H511
A000 to A959
T0000 to T4095
C0000 to C4095
D00000 to D32767
E00000 to E32767
En_00000 to En_32767
(n = 0 to C)
@ D00000 to @ D32767
@ E00000 to @ E32767
@ En_00000 to @ En_32767
(n = 0 to C)
*D00000 to *D32767
*E00000 to *E32767
*En_00000 to *En_32767
(n = 0 to C)
--- Specified values
only
--- DR0 to DR15
---
,IR0 to ,IR15
–2048 to +2047 ,IR0 to –2048 to +2047 ,IR15
DR0 to DR15, IR0 to IR15
,IR0+(++) to ,IR15+(++)
,–(– –)IR0 to, –(– –)IR15
ASCII equivalent (2 hexadecimal digits)
30 to 39
41 to 46
Section 3-12
Di D
A448 to A959
---
---
509
