Omron SYSMAC CJ - REFERENCE MANUAL 08-2008 Reference Manual page 715

Double-precision Floating-point Instructions (CS1-H, CJ1-H, CJ1M, or CS1D Only)
Ladder Symbol
Variations
Applicable Program Areas
Operand Specifications
Description
SIND(851)
S: First source word
S
D: First destination word
D
Variations Executed Each Cycle for ON Condition
Executed Once for Upward Differentiation
Executed Once for Downward Differentiation Not supported.
Immediate Refreshing Specification
Block program areas
OK OK
Area
CIO Area
Work Area
Holding Bit Area
Auxiliary Bit Area
Timer Area
Counter Area
DM Area
EM Area without bank
EM Area with bank
Indirect DM/EM
addresses in binary
Indirect DM/EM
addresses in BCD
Constants
Data Registers
Index Registers
Indirect addressing
using Index Registers
SIND(851) calculates the sine of the angle (in radians) expressed as a dou-
ble-precision (64-bit) floating-point value in words S to S+3 and places the
result in words D to D+3.
(The floating point source data must be in IEEE754 format.)
SIN( S+3 S+2
Step program areas Subroutines
OK
S
CIO 0000 to CIO 6140
W000 to W508
H000 to H508
A000 to A956
T0000 to T4092
C0000 to C4092
D00000 to D32764
E00000 to E32764
En_00000 to En_32764
(n = 0 to C)
@ D00000 to @ D32767
@ E00000 to @ E32767
@ En_00000 to @ En_32767
(n = 0 to C)
*D00000 to *D32767
*E00000 to *E32767
*En_00000 to *En_32767
(n = 0 to C)
---
---
---
,IR0 to ,IR15
–2048 to +2047 ,IR0 to –2048 to +2047 ,IR15
DR0 to DR15, IR0 to IR15
,IR0+(++) to ,IR15+(++)
,–(– –)IR0 to, –(– –)IR15
S+1 S ) D+3
Section 3-16
SIND(851)
@SIND(851)
Not supported.
Interrupt tasks
OK
D
A448 to A956
D+2 D+1 D
675
