Instruction Functions
Instruction Symbol/Operand
Mnemonic
Code
SINGLE BIT
RESET (CS1-H, RSTB(533)
CJ1-H, CJ1M, or
CS1D only)
RSTB
@RSTB
*1
!RSTB
D: Word address
*1
!@RSTB
N: Bit number
SINGLE BIT
OUTB(534)
OUTPUT (CS1-H,
CJ1-H, CJ1M, or
CS1D only)
OUTB
@OUTB
*1
!OUTB
D: Word address
N: Bit number
RSTB(533) turns OFF the specified bit in the specified word when the
execution condition is ON.
Unlike the RSET instruction, RSTB(533) can be used to reset a bit in a
D
DM or EM word.
N
OUTB(534) outputs the result (execution condition) of the logical pro-
cessing to the specified bit.
Unlike the OUT instruction, OUTB(534) can be used to control a bit in a
D
DM or EM word.
N
Function
Section 2-2
Location Page
Execution
condition
Output 201
Required
Output 204
Required
