Single Bit Set/Reset: Setb(532)/Rstb(533) - Omron SYSMAC CJ - REFERENCE MANUAL 08-2008 Reference Manual

Sequence Output Instructions
3-4-7

SINGLE BIT SET/RESET: SETB(532)/RSTB(533)

Purpose
Ladder Symbols
Variations
Applicable Program Areas
Operands
SETB(532) turns ON the specified bit.
RSTB(533) turns OFF the specified bit.
These instructions are supported by CS1-H, CJ1-H, CJ1M, and CS1D CPU
Units only.
SETB(532)
D
N
RSTB(533)
D
N
Variations Executed Each Cycle for ON Condition
Executed Once for Upward Differentiation
Executed Once for Downward Differentiation Not supported
Immediate Refreshing Specification (See note.)
Combined Executed Once and Bit Refreshed
Variations Immediately for Upward Differentiation (See
note.)
Executed Once and Bit Refreshed
Immediately for Downward Differentiation
Note Immediate refreshing is not supported by CS1D CPU Units.
Variations Executed Each Cycle for ON Condition
Executed Once for Upward Differentiation
Executed Once for Downward Differentiation Not supported
Immediate Refreshing Specification (See note.)
Combined Executed Once and Bit Refreshed
Variations Immediately for Upward Differentiation (See
note.)
Executed Once and Bit Refreshed
Immediately for Downward Differentiation
Note Immediate refreshing is not supported by CS1D CPU Units.
Block program areas
OK
D: Word Address
Specifies the word in which the bit will be turned ON or OFF.
N: Beginning Bit
Specifies the bit which will be turned ON or OFF. N must be #0000 to #000F
(&0 to &15).
D: Word address
N: Bit number
D: Word address
N: Bit number
Step program areas
OK
Section 3-4
SETB(532)
@SETB(532)
!SETB(532)
!@SETB(532)
Not supported
RSTB(533)
@RSTB(533)
!RSTB(533)
!@RSTB(533)
Not supported
Subroutines Interrupt tasks
OK OK
201
