Omron SYSMAC CJ - REFERENCE MANUAL 08-2008 Reference Manual page 822

Data Control Instructions
Variations
Applicable Program Areas
Operand Specifications
Description
782
Variations Executed Each Cycle for ON Condition
Executed Once for Upward Differentiation
Executed Once for Downward Differentiation Not supported.
Immediate Refreshing Specification
Block program areas
OK OK
Area
CIO Area
Work Area
Holding Bit Area
Auxiliary Bit Area
Timer Area
Counter Area
DM Area
EM Area without bank
EM Area with bank
Indirect DM/EM
addresses in binary
Indirect DM/EM
addresses in BCD
Constants
Data Registers
Index Registers
Indirect addressing
using Index Registers
When the execution condition is ON, BAND(681) controls output data accord-
ing to whether or not the specified input data (signed 16-bit binary) is within
the upper and lower limits (dead band). The contents of words C and C+1 are
as follows:
C Lower limit data (dead band lower limit)
C+1 Upper limit data (dead band upper limit)
C and C+1 must have the same area classification.
Step program areas Subroutines
OK
S
CIO 0000 to CIO CIO 0000 to CIO
6143 6142
W000 to W511 W000 to W510
H000 to H511 H000 to H510
A000 to A959 A000 to A958
T0000 to T4095 T0000 to T4094
C0000 to C4095 C0000 to C4094
D00000 to D00000 to
D32767 D32766
E00000 to E00000 to
E32767 E32766
En_00000 to En_00000 to
En_32767 En_32766
(n = 0 to C) (n = 0 to C)
@ D00000 to @ D32767
@ E00000 to @ E32767
@ En_00000 to @ En_32767
(n = 0 to C)
*D00000 to *D32767
*E00000 to *E32767
*En_00000 to *En_32767
(n = 0 to C)
#0000 to #FFFF ---
(binary)
DR0 to DR15 ---
---
,IR0 to ,IR15
–2048 to +2047 ,IR0 to –2048 to +2047 ,IR15
DR0 to DR15, IR0 to IR15
,IR0+(++) to ,IR15+(++)
,–(– –)IR0 to, –(– –)IR15
Section 3-18
BAND(681)
@BAND(681)
Not supported.
Interrupt tasks
OK
C D
CIO 0000 to CIO
6143
W000 to W511
H000 to H511
A448 to A959
T0000 to T4095
C0000 to C4095
D00000 to
D32767
E00000 to
E32767
En_00000 to
En_32767
(n = 0 to C)
DR0 to DR15
