Sequence Output Instructions
Variations
Applicable Program Areas
Operand Specifications
196
Variations Executed Each Cycle for ON Condition
Executed Once for Upward Differentiation
Executed Once for Downward Differentiation %SET
Immediate Refreshing Specification (See note.)
Combined Executed Once and Bit Refreshed
variations Immediately for Upward Differentiation (See
note.)
Executed Once and Bit Refreshed
Immediately for Downward Differentiation
(See note.)
Note Immediate refreshing is not supported by CS1D CPU Units.
Variations Executed Each Cycle for ON Condition
Executed Once for Upward Differentiation
Executed Once for Downward Differentiation %RSET
Immediate Refreshing Specification (See note.)
Combined Immediate Refreshing Once for Upward
Variations Differentiation (See note.)
Immediate Refreshing Once for Downward
Differentiation (See note.)
Note Immediate refreshing is not supported by CS1D CPU Units.
Block program areas
OK
Area
CIO Area
Work Area
Holding Bit Area
Auxiliary Bit Area
Timer Area
Counter Area
DM Area
EM Area without bank
EM Area with bank
Indirect DM/EM
addresses in binary
Indirect DM/EM
addresses in BCD
Constants
Data Registers
Index Registers
Indirect addressing
using Index Registers
Step program areas Subroutines
OK OK
CIO 000000 to CIO 614315
W00000 to W51115
H00000 to H51115
A44800 to A95915
---
---
---
---
---
---
---
---
---
---
,IR0 to ,IR15
–2048 to +2047, IR0 to –2048 to +2047, IR15
DR0 to DR15, IR0 to IR15
,IR0+(++) to ,IR15+(++)
,–(– –) IR0 to ,–(– –) IR15
Section 3-4
SET
@SET
!SET
!@SET
!%SET
RSET
@RSET
!RSET
!@RSET
!%RSET
Interrupt tasks
OK
B
