High-speed Counter/Pulse Output Instructions
Applicable Program Areas
Operands
Operand Specifications
888
Block program areas
OK OK
P: Port Specifier
The port specifier indicates the port. The parameters set in D and N will apply
to the next SPED(885) or ACC(888) instruction in which the same port output
location is specified.
P
0000 hex Pulse output 0
0001 hex Pulse output 1
T: Pulse Type
T specifies the type of pulses that are output as follows:
T
0000 hex Relative
0001 hex Absolute
N and N+1: Number of Pulses
N and N+1 specify the number of pulses for relative pulse output or the abso-
lute target position for absolute pulse in 8-digit hexadecimal.
15
N
Lower word with number of pulses
Upper word with number of pulses
N+1
Relative pulse output:
0 to 2,147,483,647 (0000 0000 to 7FFF FFFF hex)
Absolute pulse output:
2,147,483,648 to 2,147,483,647 (8000 0000 to 7FFF FFFF hex)
The actual number of movement pulses that will be output are as follows:
For relative pulse output, the number of movement pulses = the set number of
pulses. For absolute pulse output, the number of movement pulses = the set
number of pulses the PV.
Area
CIO Area
Work Area
Holding Bit Area
Auxiliary Bit Area
Timer Area
Counter Area
DM Area
EM Area without bank
EM Area with bank
Indirect DM/EM
addresses in binary
Indirect DM/EM
addresses in BCD
Constants
Data Registers
Step program areas Subroutines
OK
Port
Pulse type
0
P T
--- ---
--- ---
--- ---
--- ---
--- ---
--- ---
--- ---
--- ---
--- ---
--- ---
--- ---
See descrip- See descrip-
tion of oper- tion of oper-
and. and.
--- ---
Section 3-21
Interrupt tasks
OK
N
CIO 0000 to CIO 6142
W000 to W510
H000 to H510
A448 to A958
T0000 to T4094
C0000 to C4094
D00000 to D32766
---
---
@ D00000 to @ D32767
*D00000 to *D32767
See description of oper-
and.
---
