High-speed Counter/Pulse Output Instructions
Operand Specifications
870
C PRV(881) function
0002 hex Reads range comparison results.
@
3 hex P = 0000 or 0001:
00
Reads the output frequency of
pulse output 0 or pulse output 1.
P = 0010:
Reads the frequency of high-
speed counter input 0.
D: First Destination Word
The PV is output to D or to D and D+1.
15
Lower word of PV
D
D+1 Upper word of PV
2-word PV
Pulse output PV, high-speed counter input PV,
high-speed counter input frequency for high-speed counter input 0
15
D PV
1-word PV
Interrupt input PV in counter mode, status, range comparison results
Area
CIO Area
Work Area
Holding Bit Area
Auxiliary Bit Area
Timer Area
Counter Area
DM Area
EM Area without bank
EM Area with bank
Indirect DM/EM
addresses in binary
Indirect DM/EM
addresses in BCD
Constants
Data Registers
---
C = 0003 hex:
Standard operation
C = 0013 hex:
10-ms sampling method for high fre-
quency (supported only by CJ1M
CPU Units Ver. 3.0 or later)
C = 0023 hex:
100-ms sampling method for high
frequency (supported only by CJ1M
CPU Units Ver. 3.0 or later)
C = 0033 hex:
1-s sampling method for high fre-
quency (supported only by CJ1M
CPU Units Ver. 3.0 or later)
0
0
P C
--- ---
--- ---
--- ---
--- ---
--- ---
--- ---
--- ---
--- ---
--- ---
--- ---
--- ---
See descrip- See descrip-
tion of oper- tion of oper-
and. and.
--- ---
Section 3-21
Variations
D
CIO 0000 to CIO 6142
W000 to W510
H000 to H510
A448 to A958
T0000 to T4094
C0000 to C4094
D00000 to D32766
---
---
@ D00000 to @ D32766
*D00000 to *D32766
---
---
