Conversion Instructions
Operand Specifications
N: Bit Number
Specifies the bit number (0000 to 000F or &0 to &15) to be overwritten by the
source word.
Area
CIO Area
Work Area
Holding Bit Area
Auxiliary Bit Area
Timer Area
Counter Area
DM Area
EM Area without bank
EM Area with bank
Indirect DM/EM
addresses in binary
Indirect DM/EM
addresses in BCD
Constants
Data Registers
Index Registers
Indirect addressing
using Index Registers
S
CIO 0000 to CIO 0000 to
CIO 6143 CIO 6128
W000 to W511 W000 to W496
H000 to H511 H000 to H496
A000 to A959 A448 to A944
T0000 to T4095 T0000 to T4080
C0000 to C4095 C0000 to C4080
D00000 to D00000 to
D32767 D32752
E00000 to E00000 to
E32767 E32752
En_00000 to En_00000 to
En_32767 En_32752
(n = 0 to C) (n = 0 to C)
@ D00000 to @ D32767
@ E00000 to @ E32767
@ En_00000 to @ En_32767
(n = 0 to C)
*D00000 to *D32767
*E00000 to *E32767
*En_00000 to *En_32767
(n = 0 to C)
#0000 to #FFFF ---
(binary)
DR0 to DR15 ---
---
,IR0 to ,IR15
–2048 to +2047 ,IR0 to –2048 to +2047 ,IR15
DR0 to DR15, IR0 to IR15
,IR0+(++) to ,IR15+(++)
,–(– –)IR0 to, –(– –)IR15
Section 3-12
D N
CIO 0000 to
CIO 6143
W000 to W511
H000 to H511
A000 to A959
T0000 to T4095
C0000 to C4095
D00000 to
D32767
E00000 to
E32767
En_00000 to
En_32767
(n = 0 to C)
#0000 to #000F
(binary) or &0 to
&15
DR0 to DR15
515
