Omron SYSMAC CJ - REFERENCE MANUAL 08-2008 Reference Manual page 409

Data Shift Instructions
Description
Flags
Precautions
Examples
Area
EM Area without bank
EM Area with bank
Indirect DM/EM
addresses in binary
Indirect DM/EM
addresses in BCD
Constants
Data Registers
Index Registers
Indirect addressing
using Index Registers
WSFT(016) shifts data from St to E in word units and the data from the source
word S is places into St. The contents of E is lost.
Lost
Name
Error Flag
When St is greater than E, an error will be generated and the Error Flag will
turn ON.
Note When large amounts of data are shifted, the instruction execution time is quite
long. Be sure that the power is not cut while WSFT(016) is being executed,
causing the shift operation to stop halfway through.
When CIO 000000 is ON, data from CIO 0100 through CIO 0102 will be
shifted one word toward E. The contents of CIO 0300 will be stored in
CIO 0100 and the contents of CIO 0102 will be lost.
St
E
Lost
S
E00000 to E32767
En_00000 to En_32767
(n = 0 to C)
@ D00000 to @ D32767
@ E00000 to @ E32767
@ En_00000 to @ En_32767
(n = 0 to C)
*D00000 to *D32767
*E00000 to *E32767
*En_00000 to *En_32767
(n = 0 to C)
#0000 to #FFFF
(binary)
DR0 to DR15
---
,IR0 to ,IR15
–2048 to +2047 ,IR0 to –2048 to +2047 ,IR15
DR0 to DR15, IR0 to IR15
,IR0+(++) to ,IR15+(++)
,–(– –)IR0 to, –(– –)IR15
E
Label
ER ON when St is greater than E.
OFF in all other cases.
E: CIO 0100 St: CIO 0101
Section 3-9
St
---
---
St
Operation
S: CIO 0300
St: CIO 0102
E
369
