Interrupt Control Instructions
Operands
840
■
Disabling/Enabling an I/O Interrupt Task's Interrupt Input
Inputs to a CS1W-INT01/CJ1W-INT01 Interrupt Input Unit (16 inputs/Unit)
Operand
N Specify the Interrupt Input Unit's unit number.
0: Unit number 0 (interrupt tasks 100 to 115)
1: Unit number 1 (interrupt tasks 116 to 131)
C Interrupt mask.
Set to 0000 to FFFF hex.
Bits 0 to 15 correspond to each interrupt task. Individual bit settings
are as follows:
0: Enable (unmask) the interrupt.
1: Disable (mask) the interrupt.
Inputs to a C200HS-INT01 Interrupt Input Unit (8 inputs/Unit)
Operand
N Specify the Interrupt Input Unit's unit number.
0: Unit number 0 (interrupt tasks 100 to 107)
1: Unit number 1 (interrupt tasks 108 to 115)
2: Unit number 2 (interrupt tasks 116 to 123)
3: Unit number 3 (interrupt tasks 124 to 131)
C Interrupt mask.
Set to 0000 to 00FF hex
Bits 0 to 7 correspond to each interrupt task. Individual bit settings
are as follows:
0: Enable (unmasks) the interrupt.
1: Disable (masks) the interrupt.
Inputs to a CJ1M CPU Unit's Built-in Inputs (4 inputs/Unit)
Operand
N Specify the interrupt input number.
10: Interrupt input 0 (interrupt task 140)
11: Interrupt input 1 (interrupt task 141)
12: Interrupt input 2 (interrupt task 142)
13: Interrupt input 3 (interrupt task 143)
C Interrupt mask.
0000 hex: Enable (unmask) the interrupt (direct mode).
0001 hex: Disable (mask) the interrupt (direct mode).
0002 hex: Start decrementing counter and enable interrupt (counter
0003 hex: Start incrementing counter and enable interrupt (counter
Contents
Contents
Contents
mode).
mode).
Section 3-20
