Symbol Math Instructions
Description
Flags
Precautions
Examples
482
Area
Indirect DM/EM
addresses in binary
Indirect DM/EM
addresses in BCD
Constants
Data Registers
Index Registers
Indirect addressing
using Index Registers
/BL(435) divides BCD values in Dd and Dd+1 by those in Dr and Dr+1 and
outputs the quotient to R, R+1 and the remainder to R+2, R+3.
Dd + 1
÷
Dr + 1
R + 3 R + 2 R + 1
Remainder
Name Label
Error Flag ER
Equals Flag =
If Dd, Dd+1 and/or Dr, Dr+1 are not BCD or the content of Dr, Dr+1 is 0, an
error will be generated and the Error Flag will turn ON.
If as a result of the division, the content of R, R+1 is 00000000 hex, the
Equals Flag will turn ON.
When CIO 000000 is ON in the following example, D00101 and D00100 will
be divided by D00111 and D00110 as 8-digit BCD values and the quotient will
be output to D00121 and D00120 and the remainder to D00123 and D00122.
Dd
@ D00000 to @ D32767
@ E00000 to @ E32767
@ En_00000 to @ En_32767
(n = 0 to C)
*D00000 to *D32767
*E00000 to *E32767
*En_00000 to *En_32767
(n = 0 to C)
#00000000 to #00000001 to
#99999999 #99999999
(BCD) (BCD)
---
---
,IR0 to ,IR15
–2048 to +2047 ,IR0 to –2048 to +2047 ,IR15
DR0 to DR15, IR0 to IR15
,IR0+(++) to ,IR15+(++)
,–(– –)IR0 to, –(– –)IR15
(BCD)
Dd
(BCD)
Dr
R
(BCD)
Quotient
Operation
ON when Dd, Dd+1 is not BCD.
ON when Dr, Dr +1 is not BCD.
OFF in all other cases.
ON when the result is 0.
OFF in all other cases.
Section 3-11
Dr R
---
