High-speed Counter/Pulse Output Instructions
Operand Specifications
Description
866
15
Lower word of new PV
S
Upper word of new PV
S+1
For Pulse Output or High-speed Counter Input:
0000 0000 to FFFF FFFF hex
For Interrupt Input in Counter Mode:
0000 0000 to 0000 FFFF hex
Area
CIO Area
Work Area
Holding Bit Area
Auxiliary Bit Area
Timer Area
Counter Area
DM Area
EM Area without bank
EM Area with bank
Indirect DM/EM
addresses in binary
Indirect DM/EM
addresses in BCD
Constants
Data Registers
Index Registers
Indirect addressing
using Index Registers
INI(880) performs the operation specified in C for the port specified in P. The
possible combinations of operations and ports are shown in the following
table.
P: Port specifier
0000 or 0001 hex: Not allowed.
Pulse output
0010 or 0011 hex: OK
High-speed counter
input
0100, 0101, 0102, or Not allowed.
0103 hex: Interrupt
input in counter mode
1000 or 1001 hex: Not allowed.
PWM (891) output
0
P C
--- ---
--- ---
--- ---
--- ---
--- ---
--- ---
--- ---
--- ---
--- ---
--- ---
--- ---
See descrip- See descrip-
tion of oper- tion of oper-
and. and.
--- ---
--- ---
--- ---
C: Control data
0000 hex: 0001 hex:
Start Stop
comparison comparison
Not allowed.
OK
Not allowed.
Not allowed.
Section 3-21
NV
CIO 0000 to CIO 6142
W000 to W510
H000 to H510
A448 to A958
T0000 to T4094
C0000 to C4094
D00000 to D32766
---
---
@ D00000 to @ D32767
*D00000 to *D32767
---
---
---
,IR0 to ,IR15
–2048 to +2047 ,IR0 to
–2048 to +2047 ,IR15
DR0 to DR15, IR0 to
IR15
,IR0+(++) to ,IR15+(++)
,–(– –)IR0 to, –(– –)IR15
0002 hex: 0003 hex:
Change PV Stop pulse
output
OK OK
OK Not allowed.
OK Not allowed.
Not allowed. OK
