Timer and Counter Instructions
Ladder Symbol
Variations
Applicable Program Areas
Operands
Operand Specifications
260
PV
refresh
method
BCD
TMUH(541)
N
S
Binary
TMUHX(557)
N
S
Variations Executed Each Cycle for ON Condition
Executed Once for Upward Differentiation
Executed Once for Downward Differentiation Not supported.
Immediate Refreshing Specification
Function block Block program
definitions areas
OK Not allowed
N: Timer Number
The timer number must be between 0000 and 4095 (decimal).
S: Set Value
The set value must be between #0000 and 9999 (BCD).
Area
CIO Area ---
Work Area ---
Holding Bit Area ---
Auxiliary Bit Area ---
Timer Area 0000 to 4095 (decimal)
Counter Area ---
DM Area ---
EM Area without bank ---
EM Area with bank ---
Indirect DM/EM ---
addresses in binary
Symbol
N: Timer number
S: Set value
N: Timer number
S: Set value
Step program Subroutines
areas
OK OK
N
CIO 0000 to CIO 6143
W000 to W511
H000 to H511
A000 to A959
T0000 to T4095
C0000 to C4095
D00000 to D32767
E00000 to E32767
En_00000 to En_32767
(n = 0 to C)
@ D00000 to @ D32767
@ E00000 to @ E32767
@ En_00000 to
@ En_32767
(n = 0 to C)
Section 3-6
Operands
N: 0000 to 4095 (decimal)
S: #0000 to #9999 (BCD)
N: 0000 to 4095 (decimal)
S: &0 to &65535 (decimal)
#0000 to #FFFF (hex)
TMUH(544)/
TMUHX(557)
Not supported.
Not supported.
Interrupt
tasks
Not allowed
S
