High-speed Counter/Pulse Output Instructions
Operand Specifications
Description
880
15
Lower word of range 1 lower limit
TB
Upper word of range 1 lower limit
TB+1
Lower word of range 1 upper limit
TB+2
Upper word of range 1 upper limit
TB+3
Range 1 interrupt task number
Lower word of range 8 lower limit
TB+35
Upper word of range 8 lower limit
TB+36
Lower word of range 8 upper limit
TB+37
Upper word of range 8 upper limit
TB+38
Range 8 interrupt task number
TB+39
Interrupt task number
0000 to 00FF hex: Interrupt task number 0 to 255
AAAA hex:
FFFF hex:
Note Always set the upper limit greater than or equal to the lower limit for any one
range.
Area
CIO Area
Work Area
Holding Bit Area
Auxiliary Bit Area
Timer Area
Counter Area
DM Area
EM Area without bank
EM Area with bank
Indirect DM/EM
addresses in binary
Indirect DM/EM
addresses in BCD
Constants
Data Registers
Index Registers
Indirect addressing
using Index Registers
CTBL(882) registers a comparison table or registers and comparison table
and starts comparison for the port specified in P and the method specified in
C. Once a comparison table is registered, it is valid until a different table is
registered or until the CPU Unit is switched to PROGRAM mode.
Each time CTBL(882) is executed, comparison is started under the specified
conditions. When using CTBL(882) to start comparison, it is normally suffi-
0
0000 0000 to FFFF FFFF hex (See note.)
0000 0000 to FFFF FFFF hex (See note.)
0000 0000 to FFFF FFFF hex (See note.)
0000 0000 to FFFF FFFF hex (See note.)
Do not execute interrupt task.
Ignore the settings for this range.
P
--- ---
--- ---
--- ---
--- ---
--- ---
--- ---
--- ---
--- ---
--- ---
--- ---
--- ---
See descrip- See descrip-
tion of oper- tion of oper-
and. and.
--- ---
--- ---
--- ---
Section 3-21
C TB
CIO 0000 to CIO 6143
W000 to W511
H000 to H511
A448 to A959
T0000 to T4095
C0000 to C4095
D00000 to D32767
---
---
@ D00000 to @ D32767
*D00000 to *D32767
---
---
---
,IR0 to ,IR15
–2048 to +2047 ,IR0 to
–2048 to +2047 ,IR15
DR0 to DR15, IR0 to
IR15
,IR0+(++) to ,IR15+(++)
,–(– –)IR0 to, –(– –)IR15
